LN81CPH
LED ORANGE CLEAR 5MM ROUND T/HManufacturer: Panasonic Electronic Components
Categories: LED Indication - Discrete
Quality Control: Learn More
Panasonic Electronic Components LN81CPH is a through-hole mounted, 5mm round orange LED with a clear lens. This discrete indicator component operates with a typical forward voltage of 2.1V and a test current of 20mA, producing a luminous intensity of 25mcd. The peak wavelength is 630nm. Ideal for general indication and panel lighting applications across industrial and consumer electronics sectors, this component is supplied in bulk packaging. Its radial package configuration and standard design make it suitable for various mounting requirements.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Package / Case | Radial |
| Color | Orange |
| Size / Dimension | - |
| Mounting Type | Through Hole |
| Millicandela Rating | 25mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 2.1V |
| Lens Color | Colorless |
| Current - Test | 20mA |
| Viewing Angle | - |
| Height (Max) | 11.65mm |
| Wavelength - Peak | 630nm |
| Wavelength - Dominant | - |
| Supplier Device Package | 5mm Round |
| Lens Transparency | Clear |
| Lens Style | Round with Domed Top |
| Lens Size | 5mm, T-1 3/4 |
