CND0216A
IRDA MODULE 115.2KBPS 9 PIN SMDManufacturer: Panasonic Electronic Components
Categories: IrDA Transceiver Modules
Quality Control: Learn More
Panasonic Electronic Components CND0216A is an SIR (Standard Infrared) IrDA transceiver module operating at a data rate of 115.2kbs. This top-view, 9-pin SMD component features a low idle current of 200 nA typical at 25°C and a low power link range of 40cm. The module supports a shutdown mode, enhancing power efficiency. It operates within a supply voltage range of 2.8 V to 4.5 V and has an operating temperature range of -30°C to 85°C. The compact dimensions are 8.2mm x 1.6mm x 2.0mm. This component is commonly utilized in industrial automation and medical device applications where reliable, short-range serial communication is required. It is supplied in Tape & Reel packaging.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Orientation | Top View |
| Operating Temperature | -30°C ~ 85°C |
| Size | 8.2mm x 1.6mm x 2.0mm |
| Data Rate | 115.2kbs (SIR) |
| Standards | - |
| Link Range, Low Power | 40cm |
| Shutdown | Yes |
| Voltage - Supply | 2.8 V ~ 4.5 V |
| Idle Current, Typ @ 25°C | 200 nA |
