AN44070A-VF
IC HALF BRIDGE DRVR 2.5A 24HQFNManufacturer: Panasonic Electronic Components
Categories: Full Half-Bridge (H Bridge) Drivers
Quality Control: Learn More
Panasonic Electronic Components AN44070A-VF is a BCDMOS half-bridge driver designed for DC motor control and general-purpose applications. This component delivers 2.5A of output current per channel and operates from a 3V to 5.5V supply voltage, supporting load voltages up to 34V. The AN44070A-VF features integrated fault protection, including current limiting, over-temperature protection, and undervoltage lockout (UVLO). Its interface utilizes PWM signals, and it is configured for a half-bridge output. The device is packaged in a 24-HQFN (4x4) with an exposed pad, suitable for surface mounting. It is commonly employed in automotive and industrial automation systems.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 24-WFQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Interface | PWM |
| Operating Temperature | -20°C ~ 70°C (TA) |
| Output Configuration | Half Bridge (4) |
| Voltage - Supply | 3V ~ 5.5V |
| Rds On (Typ) | - |
| Applications | DC Motors, General Purpose |
| Current - Output / Channel | 2.5A |
| Current - Peak Output | - |
| Technology | BCDMOS |
| Voltage - Load | 10V ~ 34V |
| Supplier Device Package | 24-HQFN (4x4) |
| Fault Protection | Current Limiting, Over Temperature, UVLO |
| Load Type | Inductive |
