FC8J33040L
MOSFET 2N-CH 33V 5A WMINI8-F1Manufacturer: Panasonic Electronic Components
Categories: FET, MOSFET Arrays
Quality Control: Learn More
Panasonic Electronic Components FC8J33040L is a dual N-channel MOSFET array designed for high-density applications. This WMini8-F1 packaged device offers a 33V Drain-to-Source voltage (Vdss) and a continuous drain current capability of 5A at 25°C. Featuring a low on-resistance of 38mOhm at 2.5A and 10V (Id, Vgs), this MOSFET array is optimized for efficient power switching. The input capacitance (Ciss) is rated at a maximum of 220pF at 10V, with a gate charge (Qg) of 2.8nC at 4.5V. Operating at temperatures up to 150°C (TJ), the FC8J33040L is suitable for use in automotive and industrial control systems. The device is supplied in Tape & Reel packaging and is available in a surface mount configuration.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SMD, Flat Leads |
| Mounting Type | Surface Mount |
| Configuration | 2 N-Channel (Dual) |
| Operating Temperature | 150°C (TJ) |
| Technology | MOSFET (Metal Oxide) |
| Power - Max | 1W |
| Drain to Source Voltage (Vdss) | 33V |
| Current - Continuous Drain (Id) @ 25°C | 5A |
| Input Capacitance (Ciss) (Max) @ Vds | 220pF @ 10V |
| Rds On (Max) @ Id, Vgs | 38mOhm @ 2.5A, 10V |
| Gate Charge (Qg) (Max) @ Vgs | 2.8nC @ 4.5V |
| FET Feature | - |
| Vgs(th) (Max) @ Id | 2.5V @ 260µA |
| Supplier Device Package | WMini8-F1 |
