EVE-UBCAH516B
ROTARY ENCODER MECHANICAL 16PPRManufacturer: Panasonic Electronic Components
Categories: Encoders
Quality Control: Learn More
Panasonic Electronic Components EVE-UBCAH516B is a mechanical rotary encoder designed for surface mount applications. This vertical mount encoder features a 16 pulses per revolution quadrature (incremental) output, providing precise rotational feedback. The actuator is an 8mm diameter flatted end, and the unit includes a built-in switch with detent functionality. With a rotational life expectancy of a minimum of 30,000 cycles and a supply voltage of 5V, the EVE-UBCAH516B is suited for applications demanding robust and reliable position sensing. This component is commonly utilized in industrial control, consumer electronics, and automotive systems. The termination style is solder tab, and it is supplied in tray packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 18 week(s)Product Status: Not For New DesignsPackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Output Type | Quadrature (Incremental) |
| Mounting Type | Surface Mount |
| Orientation | Vertical |
| Termination Style | Solder Tab |
| Voltage - Supply | 5V |
| Encoder Type | Mechanical |
| Detent | Yes |
| Pulses per Revolution | 16 |
| Actuator Type | 8mm Dia Flatted End |
| Built in Switch | Yes |
| Rotational Life (Cycles Min) | 30k |
| Programmable | Not Verified |
