NN30320A-VB
IC REG BUCK ADJ 3A 24QFNManufacturer: Panasonic Electronic Components
Categories: DC DC Switching Regulators
Quality Control: Learn More
Panasonic Electronic Components NN30320A-VB is a versatile buck switching regulator IC designed for step-down voltage conversion. This adjustable positive output regulator supports a minimum output voltage of 0.75V and can deliver up to 3A of output current. Featuring selectable switching frequencies of 210kHz, 430kHz, and 650kHz, it offers flexibility in optimizing performance for various applications. The NN30320A-VB operates with input voltages ranging from 4.5V to 28V and is housed in a 24-WFQFN exposed pad package, suitable for surface mounting. Its design includes a synchronous rectifier for improved efficiency. This component finds application in industrial, automotive, and consumer electronics sectors requiring efficient power management.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 24-WFQFN Exposed Pad |
| Output Type | Adjustable |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Function | Step-Down |
| Current - Output | 3A |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Output Configuration | Positive |
| Frequency - Switching | 210kHz, 430kHz, 650kHz |
| Voltage - Input (Max) | 28V |
| Topology | Buck |
| Supplier Device Package | 24-QFN (4x4) |
| Synchronous Rectifier | Yes |
| Voltage - Output (Max) | 5.5V |
| Voltage - Input (Min) | 4.5V |
| Voltage - Output (Min/Fixed) | 0.75V |
