AN8017SA-E1
IC REG CTRLR BOOST 16SSOPManufacturer: Panasonic Electronic Components
Categories: DC DC Switching Controllers
Quality Control: Learn More
Panasonic Electronic Components AN8017SA-E1 is a versatile Boost regulator controller designed for positive output step-up DC-DC conversion. This IC offers a broad input voltage range from 1.8V to 14V and operates with a switching frequency adjustable from 20kHz up to 1MHz. Key control features include current limiting, dead time control, and an enable function, providing robust operational management. The AN8017SA-E1 is configured with two outputs and a single output phase, utilizing a transistor driver for the output stage. Its 16-SSOP package facilitates surface mounting, making it suitable for various applications in the automotive and industrial sectors. The device operates within an ambient temperature range of -30°C to 85°C.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 16-LSSOP (0.173"", 4.40mm Width) |
| Output Type | Transistor Driver |
| Mounting Type | Surface Mount |
| Function | Step-Up |
| Operating Temperature | -30°C ~ 85°C (TA) |
| Output Configuration | Positive |
| Frequency - Switching | 20kHz ~ 1MHz |
| Topology | Boost |
| Voltage - Supply (Vcc/Vdd) | 1.8V ~ 14V |
| Supplier Device Package | 16-SSOP |
| Synchronous Rectifier | No |
| Control Features | Current Limit, Dead Time Control, Enable |
| Serial Interfaces | - |
| Output Phases | 1 |
| Duty Cycle (Max) | 77%, 78% |
| Clock Sync | No |
| Number of Outputs | 2 |
