ERJ-8ENF10R0V

RES SMD 10 OHM 1% 1/4W 1206

Manufacturer: Panasonic Electronic Components

Categories: Chip Resistor - Surface Mount

Quality Control: Learn More

Panasonic Electronic Components ERJ-8EN series thick film chip resistor, part number ERJ-8ENF10R0V, offers a 10 Ohm resistance with a ±1% tolerance. This surface mount component is rated for 0.25W (1/4W) power dissipation and features a ±100ppm/°C temperature coefficient. The 1206 (3216 Metric) package measures 0.126" L x 0.063" W (3.20mm x 1.60mm) with a maximum seated height of 0.028" (0.70mm). Designed for demanding applications, it meets the AEC-Q200 automotive qualification standards. Operating temperature range is -55°C to 155°C. Supplied on tape and reel (TR), this resistor is suitable for automotive electronics, industrial control systems, and consumer electronics.

Additional Information

Series: ERJ-8ENRoHS Status: ROHS3 CompliantManufacturer Lead Time: 22 week(s)Product Status: Not For New DesignsPackaging: Tape & Reel (TR)Datasheet:
Technical Details:
Power (Watts)0.25W, 1/4W
Tolerance±1%
FeaturesAutomotive AEC-Q200
PackagingTape & Reel (TR)
Package / Case1206 (3216 Metric)
Temperature Coefficient±100ppm/°C
Size / Dimension0.126"" L x 0.063"" W (3.20mm x 1.60mm)
CompositionThick Film
Operating Temperature-55°C ~ 155°C
RatingsAEC-Q200
Number of Terminations2
Supplier Device Package1206
Height - Seated (Max)0.028"" (0.70mm)
Failure Rate-
Resistance10 Ohms
