AN7512
IC AMP CLASS AB STEREO 1W 16DIPManufacturer: Panasonic Electronic Components
Categories: Audio Amplifiers
Quality Control: Learn More
Panasonic Electronic Components AN7512 is a 2-channel Class AB audio amplifier IC designed for stereo applications. This through-hole component, housed in a 16-DIP package with a ground tab, delivers 1W per channel into an 8-ohm load. The AN7512 operates from a supply voltage range of 3.5V to 13.5V and features integrated standby mode, thermal protection, and volume control functionality, simplifying system design. Its robust design makes it suitable for a variety of audio systems, including consumer electronics and industrial audio equipment. The operating temperature range is -25°C to 70°C (TA).
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Features | Standby, Thermal Protection, Volume Control |
| Packaging | Tube |
| Package / Case | 16-DIP (0.300"", 7.62mm) + Ground Tab |
| Output Type | 2-Channel (Stereo) |
| Mounting Type | Through Hole |
| Type | Class AB |
| Operating Temperature | -25°C ~ 70°C (TA) |
| Voltage - Supply | 3.5V ~ 13.5V |
| Max Output Power x Channels @ Load | 1W x 2 @ 8Ohm |
| Supplier Device Package | 16-DIP |
