AN17832A
IC AMP CLASS AB 3 CHAN 30W 12SILManufacturer: Panasonic Electronic Components
Categories: Audio Amplifiers
Quality Control: Learn More
Panasonic Electronic Components AN17832A is a 3-channel Class AB audio amplifier IC housed in a 12-SIL package with a tab. This component delivers up to 30W into an 8-ohm load for a single channel, or 15W into a 4-ohm load for two channels. Integrated features include mute and standby functions for power management, along with comprehensive thermal protection. The AN17832A supports a wide supply voltage range from ±5V to ±15V, making it suitable for a variety of audio applications. Its through-hole mounting type facilitates integration into existing designs. This amplifier is commonly utilized in automotive audio systems and home entertainment equipment demanding robust audio amplification.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Features | Mute, Standby, Thermal Protection |
| Packaging | Tube |
| Package / Case | 12-SIP + Tab |
| Output Type | 3-Channel |
| Mounting Type | Through Hole |
| Type | Class AB |
| Operating Temperature | - |
| Voltage - Supply | ±5V ~ 15V |
| Max Output Power x Channels @ Load | 30W x 1 @ 8Ohm; 15W x 2 @ 4Ohm |
| Supplier Device Package | 12-SIL |
