VS5-24V
IC HALF BRIDGE DRVR 24VManufacturer: Panasonic Electric Works
Categories: Full Half-Bridge (H Bridge) Drivers
Quality Control: Learn More
Panasonic Electric Works VS5-24V is a bipolar half-bridge driver designed for efficient control of inductive loads, particularly relays. This through-hole mounted module operates within a supply voltage range of 4V to 30V, with an output configuration supporting half-bridge operation. The VS5-24V facilitates logic-level interfacing for seamless integration into control systems. Its robust design is suitable for applications in automotive, industrial automation, and power control systems where reliable relay switching is critical. The operating temperature range is -20°C to 80°C (TA).
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: -Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | - |
| Package / Case | Module |
| Mounting Type | Through Hole |
| Interface | Logic |
| Operating Temperature | -20°C ~ 80°C (TA) |
| Output Configuration | Half Bridge |
| Voltage - Supply | 4V ~ 30V |
| Rds On (Typ) | - |
| Applications | Relays |
| Current - Output / Channel | - |
| Current - Peak Output | - |
| Technology | Bipolar |
| Voltage - Load | - |
| Supplier Device Package | - |
| Fault Protection | - |
| Load Type | Inductive |
