AM-1454CA-DGK-E
AMORPHOUS SOLAR CELL 46.5UW 2.4VManufacturer: Panasonic - BSG
Categories: Solar Cells
Quality Control: Learn More
Amorphous Solar Cell 46.5 µW 2.4 V
Additional Information
Series: AmortonRoHS Status: RoHS CompliantManufacturer Lead Time: 11 week(s)Product Status: ActivePackaging: BoxDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Box |
| Package / Case | Cells |
| Size / Dimension | 1.638"" L x 1.035"" W x 0.043"" H (41.60mm x 26.30mm x 1.10mm) |
| Type | Amorphous |
| Operating Temperature | -10°C ~ 60°C |
| Voltage @ Pmpp | 1.5 V |
| Current @ Pmpp | 31 µA |
| Voltage - Open Circuit | 2.4 V |
| Current - Short Circuit (Isc) | 35 µA |
| Power (Watts) - Max | 46.5 µW |
Request a Quote
