ODD-525W
SENSOR PHOTODIODE 525NM T/HManufacturer: Opto Diode Corp
Categories: Photodiodes
Quality Control: Learn More
Opto Diode Corp ODD-525W is a silicon photodiode with a peak spectral response at 525nm. This through-hole mounted component features a 0.62mm² active area and a fast 35ns response time, making it suitable for applications requiring precise optical detection. The photodiode exhibits a typical dark current of 30pA and a maximum reverse voltage of 5V. Its spectral range extends from 370nm to 600nm, with a responsivity of 0.3 A/W at 525nm. The ODD-525W is rated for operation between -30°C and 85°C and is supplied in bulk packaging. This component finds application in industrial automation, medical instrumentation, and optical sensing systems.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | - |
| Wavelength | 525nm |
| Mounting Type | Through Hole |
| Diode Type | - |
| Operating Temperature | -30°C ~ 85°C |
| Response Time | 35ns |
| Viewing Angle | - |
| Spectral Range | 370nm ~ 600nm |
| Color - Enhanced | - |
| Responsivity @ nm | 0.3 A/W @ 525nm |
| Active Area | 0.62mm² |
| Current - Dark (Typ) | 30pA |
| Voltage - DC Reverse (Vr) (Max) | 5 V |
