TRA2532
TVS DIODE 23VWM MICRODE BUTTONManufacturer: onsemi
Categories: TVS Diodes
Quality Control: Learn More
onsemi TVS Diode, TRA2532, is a robust transient voltage suppressor designed for demanding applications. This surface mount component, housed in a Microde Button package, offers a reverse standoff voltage of 23V and a minimum breakdown voltage of 24V. It features a single unidirectional channel for effective protection against voltage transients. The TRA2532 operates reliably across a wide temperature range of -65°C to 175°C (TJ). Its construction is suitable for general-purpose applications, finding utility in industries such as automotive, industrial control, and consumer electronics where robust overvoltage protection is critical.
Additional Information
Series: -RoHS Status: RoHS Compliant By ExemptionManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | Microde Button |
| Mounting Type | Surface Mount |
| Type | Zener |
| Operating Temperature | -65°C ~ 175°C (TJ) |
| Applications | General Purpose |
| Capacitance @ Frequency | - |
| Current - Peak Pulse (10/1000µs) | - |
| Voltage - Reverse Standoff (Typ) | 23V |
| Supplier Device Package | Microde Button |
| Unidirectional Channels | 1 |
| Voltage - Breakdown (Min) | 24V |
| Voltage - Clamping (Max) @ Ipp | - |
| Power - Peak Pulse | - |
| Power Line Protection | No |
