P6SMB16CAT3
TVS DIODE 13.6VWM 22.5VC SMBManufacturer: onsemi
Categories: TVS Diodes
Quality Control: Learn More
The onsemi P6SMB16CAT3 is a 600W transient voltage suppressor (TVS) diode designed for robust protection in demanding applications. This SMB package (DO-214AA) device offers a reverse standoff voltage of 13.6V and a breakdown voltage of 15.2V. It features a clamping voltage of 22.5V at a peak pulse current of 27A (10/1000µs), providing effective safeguarding against voltage transients. With a 1MHz capacitance of 610pF and a single bidirectional channel, it is suitable for board-level protection. The P6SMB16CAT3 boasts an operating temperature range of -65°C to 150°C and is qualified to AEC-Q101 standards, making it ideal for automotive applications. This component is supplied in Tape & Reel (TR) packaging for efficient automated assembly.
Additional Information
Series: -RoHS Status: RoHS Compliant By ExemptionManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | DO-214AA, SMB |
| Mounting Type | Surface Mount |
| Type | Zener |
| Operating Temperature | -65°C ~ 150°C (TJ) |
| Applications | - |
| Capacitance @ Frequency | 610pF @ 1MHz |
| Current - Peak Pulse (10/1000µs) | 27A |
| Voltage - Reverse Standoff (Typ) | 13.6V |
| Supplier Device Package | SMB |
| Bidirectional Channels | 1 |
| Voltage - Breakdown (Min) | 15.2V |
| Voltage - Clamping (Max) @ Ipp | 22.5V |
| Power - Peak Pulse | 600W |
| Power Line Protection | No |
| Grade | Automotive |
| Qualification | AEC-Q101 |
