1SMC16AT3
TVS DIODE 16VWM 26VC SMCManufacturer: onsemi
Categories: TVS Diodes
Quality Control: Learn More
onsemi 1SMC16AT3 is a transient voltage suppressor (TVS) diode designed for surface mount applications. This SMC package (DO-214AB) component offers a reverse standoff voltage of 16V and a breakdown voltage (VBR) of 17.8V minimum. It features a peak pulse current (IPP) handling capability of 57.7A with a peak pulse power (PPP) rating of 1500W (1.5kW). The device provides a clamping voltage of 26V at 57.7A. Operating across a temperature range of -65°C to 150°C, the 1SMC16AT3 is suitable for general-purpose protection applications, commonly found in automotive and industrial systems requiring robust overvoltage protection. It is supplied in Tape & Reel packaging.
Additional Information
Series: -RoHS Status: RoHS Compliant By ExemptionManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | DO-214AB, SMC |
| Mounting Type | Surface Mount |
| Type | Zener |
| Operating Temperature | -65°C ~ 150°C (TJ) |
| Applications | General Purpose |
| Capacitance @ Frequency | - |
| Current - Peak Pulse (10/1000µs) | 57.7A |
| Voltage - Reverse Standoff (Typ) | 16V |
| Supplier Device Package | SMC |
| Unidirectional Channels | 1 |
| Voltage - Breakdown (Min) | 17.8V |
| Voltage - Clamping (Max) @ Ipp | 26V |
| Power - Peak Pulse | 1500W (1.5kW) |
| Power Line Protection | No |
| Grade | - |
| Qualification | - |
