1SMB30CAT3
TVS DIODE 30VWM 48.4VC SMBManufacturer: onsemi
Categories: TVS Diodes
Quality Control: Learn More
The onsemi 1SMB30CAT3 is a transient voltage suppressor (TVS) diode designed for robust overvoltage protection. This unidirectional device, housed in the SMB (DO-214AA) package, offers a reverse standoff voltage of 30V and a minimum breakdown voltage of 33.3V. It features a 48.4V maximum clamping voltage at a peak pulse current of 12.4A (10/1000µs), providing 600W of peak pulse power dissipation. The diode exhibits a typical capacitance of 290pF at 1MHz. Operating across a wide temperature range of -65°C to 150°C, the 1SMB30CAT3 is suitable for general-purpose applications, including automotive and industrial electronics requiring protection against voltage transients. Supplied in Tape & Reel packaging.
Additional Information
Series: -RoHS Status: RoHS Compliant By ExemptionManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | DO-214AA, SMB |
| Mounting Type | Surface Mount |
| Type | Zener |
| Operating Temperature | -65°C ~ 150°C (TJ) |
| Applications | General Purpose |
| Capacitance @ Frequency | 290pF @ 1MHz |
| Current - Peak Pulse (10/1000µs) | 12.4A |
| Voltage - Reverse Standoff (Typ) | 30V |
| Supplier Device Package | SMB |
| Bidirectional Channels | 1 |
| Voltage - Breakdown (Min) | 33.3V |
| Voltage - Clamping (Max) @ Ipp | 48.4V |
| Power - Peak Pulse | 600W |
| Power Line Protection | No |
| Grade | - |
| Qualification | - |
