1SMA60CAT3
TVS DIODE 60VWM 96.8VC SMAManufacturer: onsemi
Categories: TVS Diodes
Quality Control: Learn More
The onsemi 1SMA60CAT3 is a transient voltage suppressor (TVS) diode designed for robust overvoltage protection. Featuring a 60V reverse standoff voltage and a 96.8V maximum clamping voltage at a peak pulse current of 4.1A (10/1000µs), this device offers 400W of peak pulse power dissipation. Its bidirectional design and low capacitance of 110pF at 1MHz make it suitable for general-purpose applications. The 1SMA60CAT3 is housed in a DO-214AC, SMA surface-mount package and operates within a temperature range of -65°C to 150°C. This component is commonly utilized in automotive and industrial electronics for safeguarding sensitive circuitry from transient voltage spikes. It is supplied in Tape & Reel packaging.
Additional Information
Series: -RoHS Status: RoHS Compliant By ExemptionManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | DO-214AC, SMA |
| Mounting Type | Surface Mount |
| Type | Zener |
| Operating Temperature | -65°C ~ 150°C (TJ) |
| Applications | General Purpose |
| Capacitance @ Frequency | 110pF @ 1MHz |
| Current - Peak Pulse (10/1000µs) | 4.1A |
| Voltage - Reverse Standoff (Typ) | 60V |
| Supplier Device Package | SMA |
| Bidirectional Channels | 1 |
| Voltage - Breakdown (Min) | 66.7V |
| Voltage - Clamping (Max) @ Ipp | 96.8V |
| Power - Peak Pulse | 400W |
| Power Line Protection | No |
| Grade | - |
| Qualification | - |
