MOC3033VM
OPTOISOLATOR 4.17KV TRIAC 6DIPManufacturer: onsemi
Categories: Triac, SCR Output Optoisolators
Quality Control: Learn More
The onsemi MOC3033VM is a single-channel optoisolator featuring a Triac output. This device provides 4170Vrms of isolation and is designed for applications requiring the control of AC loads. The output stage is a non-zero-crossing Triac, suitable for switching resistive loads. Key electrical specifications include a forward voltage (Vf) of 1.25V (typical), a forward current (If) of up to 60mA, and a minimum LED trigger current (Ift) of 5mA. The Triac output has a static dV/dt rating of 1kV/µs (minimum) and an off-state voltage of 250V. The component is housed in a 6-DIP package and is suitable for through-hole mounting. It operates within a temperature range of -40°C to 85°C. This optoisolator finds application in solid-state relays, power control systems, and industrial automation. It holds approvals from IEC/EN/DIN and UL.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 6-DIP (0.300"", 7.62mm) |
| Output Type | Triac |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Forward (Vf) (Typ) | 1.25V |
| Voltage - Isolation | 4170Vrms |
| Approval Agency | IEC/EN/DIN, UL |
| Current - Hold (Ih) | 400µA (Typ) |
| Turn On Time | - |
| Supplier Device Package | 6-DIP |
| Zero Crossing Circuit | Yes |
| Static dV/dt (Min) | 1kV/µs |
| Current - LED Trigger (Ift) (Max) | 5mA |
| Number of Channels | 1 |
| Voltage - Off State | 250 V |
| Current - DC Forward (If) (Max) | 60 mA |
