MOC3011VM
OPTOISOLATOR 4.17KV TRIAC 6DIPManufacturer: onsemi
Categories: Triac, SCR Output Optoisolators
Quality Control: Learn More
The onsemi TRIAC output optoisolator, part number MOC3011VM, provides 4170Vrms isolation in a 6-DIP package. This single-channel device features a Triac output capable of handling 250V off-state voltage. It requires a maximum DC forward current of 60mA and a typical holding current of 100µA. The LED trigger current (Ift) is a maximum of 10mA, with a typical forward voltage (Vf) of 1.15V. Designed for through-hole mounting, the MOC3011VM is suitable for applications requiring isolation between low-voltage control circuits and higher-voltage AC loads. It is approved by IEC/EN/DIN and UL, and operates within a temperature range of -40°C to 85°C. This component is commonly utilized in power control systems, solid-state relays, and industrial automation.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 6-DIP (0.300"", 7.62mm) |
| Output Type | Triac |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Forward (Vf) (Typ) | 1.15V |
| Voltage - Isolation | 4170Vrms |
| Approval Agency | IEC/EN/DIN, UL |
| Current - Hold (Ih) | 100µA (Typ) |
| Turn On Time | - |
| Supplier Device Package | 6-DIP |
| Zero Crossing Circuit | No |
| Static dV/dt (Min) | - |
| Current - LED Trigger (Ift) (Max) | 10mA |
| Number of Channels | 1 |
| Voltage - Off State | 250 V |
| Current - DC Forward (If) (Max) | 60 mA |
