MOC8204W
OPTOISO 5.3KV TRANS W/BASE 6DIPManufacturer: onsemi
Categories: Transistor, Photovoltaic Output Optoisolators
Quality Control: Learn More
The onsemi MOC8204W is a single-channel optocoupler featuring a transistor output with a base connection. This device provides 5300Vrms isolation, making it suitable for applications requiring robust electrical separation. It operates with a DC input and exhibits a minimum Current Transfer Ratio (CTR) of 20% at 10mA forward current, with a maximum DC forward current of 60mA. The output transistor has a Vce(sat) of 400mV (max) and can handle output voltages up to 400V. Turn-on and turn-off times are specified at 5µs. The MOC8204W is housed in a 6-DIP package and is designed for through-hole mounting. Typical applications include power supply control, industrial automation, and telecommunications equipment.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 6-DIP (0.400"", 10.16mm) |
| Output Type | Transistor with Base |
| Mounting Type | Through Hole |
| Operating Temperature | -55°C ~ 100°C |
| Voltage - Forward (Vf) (Typ) | 1.2V |
| Input Type | DC |
| Current - Output / Channel | 2mA |
| Voltage - Isolation | 5300Vrms |
| Current Transfer Ratio (Min) | 20% @ 10mA |
| Vce Saturation (Max) | 400mV |
| Current Transfer Ratio (Max) | - |
| Supplier Device Package | 6-DIP |
| Voltage - Output (Max) | 400V |
| Turn On / Turn Off Time (Typ) | 5µs, 5µs |
| Rise / Fall Time (Typ) | - |
| Number of Channels | 1 |
| Current - DC Forward (If) (Max) | 60 mA |
