MOC206R2VM
OPTOISO 2.5KV TRANS W/BASE 8SOICManufacturer: onsemi
Categories: Transistor, Photovoltaic Output Optoisolators
Quality Control: Learn More
The onsemi MOC206R2VM is a single-channel optoisolator featuring a transistor output with a base connection. This component provides 2500Vrms of isolation and is housed in an 8-SOIC package suitable for surface mounting. Key electrical specifications include a DC forward current (If) of up to 60mA and an output current capability of 150mA per channel. The device exhibits a typical forward voltage (Vf) of 1.15V. Current transfer ratios range from a minimum of 63% to a maximum of 125% at 10mA input current. Switching characteristics include typical rise and fall times of 3.2µs and 4.7µs respectively, with turn-on and turn-off times of 7.5µs and 5.7µs. The device operates within a temperature range of -40°C to 100°C and has a Vce saturation of 400mV maximum. This optoisolator is commonly employed in industrial automation, power supply control, and telecommunications applications.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Output Type | Transistor with Base |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 100°C |
| Voltage - Forward (Vf) (Typ) | 1.15V |
| Input Type | DC |
| Current - Output / Channel | 150mA |
| Voltage - Isolation | 2500Vrms |
| Current Transfer Ratio (Min) | 63% @ 10mA |
| Vce Saturation (Max) | 400mV |
| Current Transfer Ratio (Max) | 125% @ 10mA |
| Supplier Device Package | 8-SOIC |
| Voltage - Output (Max) | 30V |
| Turn On / Turn Off Time (Typ) | 7.5µs, 5.7µs |
| Rise / Fall Time (Typ) | 3.2µs, 4.7µs |
| Number of Channels | 1 |
| Current - DC Forward (If) (Max) | 60 mA |
Request a Quote
Clients Also Buy
HMHA281R2V
