CPH5901F-TL-E
TRANS NPN/JFET N-CH 15V CPH5Manufacturer: onsemi
Categories: Special Purpose
Quality Control: Learn More
The onsemi CPH5901F-TL-E is a versatile bipolar transistor and field-effect transistor combination, designed for demanding applications. This device integrates an NPN bipolar junction transistor with a P-channel JFET, offering unique performance characteristics. Rated for a collector-emitter voltage of 50V and a continuous collector current of 150mA, it provides robust amplification capabilities. The CPH5901F-TL-E is housed in a compact 5-CPH (SOT-23-5 Thin, TSOT-23-5) surface-mount package, facilitating high-density board designs. Its integrated nature makes it suitable for amplifier circuits, signal switching, and other specialized functions across various electronic systems, including consumer electronics and industrial control. The component is supplied in bulk packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Voltage - Rated | 50V |
| Package / Case | SOT-23-5 Thin, TSOT-23-5 |
| Current Rating (Amps) | 150mA |
| Mounting Type | Surface Mount |
| Transistor Type | NPN + FET |
| Applications | Amplifier |
| Supplier Device Package | 5-CPH |
