LA72730-N-E
IC AUDIO/VIDEO SWITCH TV 24SDIPManufacturer: onsemi
Categories: Special Purpose
Quality Control: Learn More
The onsemi LA72730-N-E is a versatile audio/video switch IC designed for signal routing in television and multimedia systems. This component features three distinct audio/video channels, each capable of handling complex signal switching. The device integrates a 5:1 multiplexer/demultiplexer circuit, enabling flexible input selection for each channel. With a -3dB bandwidth of 10MHz, it supports standard definition video signals.
Key features include I2C control for seamless integration into digital control systems and an ALC (Automatic Level Control) output, which is beneficial for audio processing. The LA72730-N-E operates from a single 4.5V to 5.5V supply and is housed in a 24-SDIP through-hole package, facilitating robust board assembly. Its wide operating temperature range of -20°C to 70°C makes it suitable for various environmental conditions. This IC finds application in consumer electronics, broadcast equipment, and other systems requiring efficient audio and video signal management.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Features | I2C, ALC Output |
| Packaging | Tube |
| Package / Case | 24-SDIP (0.300"", 7.62mm) |
| Mounting Type | Through Hole |
| Operating Temperature | -20°C ~ 70°C (TA) |
| Applications | Audio, Video |
| On-State Resistance (Max) | - |
| -3db Bandwidth | 10MHz |
| Supplier Device Package | 24-SDIP |
| Voltage - Supply, Single (V+) | 4.5V ~ 5.5V |
| Voltage - Supply, Dual (V±) | - |
| Switch Circuit | - |
| Multiplexer/Demultiplexer Circuit | 5:1 |
| Number of Channels | 3 |
