SZMMSZ15T1G
DIODE ZENER 15V 500MW SOD123Manufacturer: onsemi
Categories: Single Zener Diodes
Quality Control: Learn More
Zener Diode 15 V 500 mW ±5% Surface Mount SOD-123
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 13 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Tolerance | ±5% |
| Packaging | Tape & Reel (TR) |
| Package / Case | SOD-123 |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 150°C |
| Voltage - Zener (Nom) (Vz) | 15 V |
| Impedance (Max) (Zzt) | 30 Ohms |
| Supplier Device Package | SOD-123 |
| Grade | Automotive |
| Power - Max | 500 mW |
| Voltage - Forward (Vf) (Max) @ If | 900 mV @ 10 mA |
| Current - Reverse Leakage @ Vr | 50 nA @ 10.5 V |
| Qualification | AEC-Q101 |
