MMSZ4693ET1
DIODE ZENER 7.5V 500MW SOD123Manufacturer: onsemi
Categories: Single Zener Diodes
Quality Control: Learn More
The onsemi MMSZ4693ET1 is a Zener diode with a nominal Zener voltage (Vz) of 7.5 V and a maximum power dissipation of 500 mW. This device features a ±5% tolerance and a low reverse leakage current of 10 µA at 5.7 V. The forward voltage (Vf) at 10 mA is a maximum of 900 mV. Designed for surface mounting, it is supplied in a compact SOD-123 package and is available on tape and reel. The operating temperature range is from -55°C to 150°C. This component finds application in voltage regulation and reference circuits across various industrial and consumer electronics sectors.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Tolerance | ±5% |
| Packaging | Tape & Reel (TR) |
| Package / Case | SOD-123 |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 150°C |
| Voltage - Zener (Nom) (Vz) | 7.5 V |
| Supplier Device Package | SOD-123 |
| Grade | - |
| Power - Max | 500 mW |
| Voltage - Forward (Vf) (Max) @ If | 900 mV @ 10 mA |
| Current - Reverse Leakage @ Vr | 10 µA @ 5.7 V |
| Qualification | - |
