NTMFS4D0N08XT1G
T10 80V STD NCH MOSFET SO8FLManufacturer: onsemi
Categories: Single FETs, MOSFETs
Quality Control: Learn More
N-Channel 80 V 119A (Tc) 107W (Tc) Surface Mount 5-DFN (5x6) (8-SOFL)
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 35 week(s)Product Status: ActivePackaging: Cut Tape (CT)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Cut Tape (CT) |
| Package / Case | 8-PowerTDFN, 5 Leads |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Technology | MOSFET (Metal Oxide) |
| FET Type | N-Channel |
| Current - Continuous Drain (Id) @ 25°C | 119A (Tc) |
| Rds On (Max) @ Id, Vgs | 3.5mOhm @ 27A, 10V |
| FET Feature | - |
| Power Dissipation (Max) | 107W (Tc) |
| Vgs(th) (Max) @ Id | 3.6V @ 133µA |
| Supplier Device Package | 5-DFN (5x6) (8-SOFL) |
| Grade | - |
| Drive Voltage (Max Rds On, Min Rds On) | 6V, 10V |
| Vgs (Max) | ±20V |
| Drain to Source Voltage (Vdss) | 80 V |
| Gate Charge (Qg) (Max) @ Vgs | 33 nC @ 10 V |
| Input Capacitance (Ciss) (Max) @ Vds | 2400 pF @ 40 V |
| Qualification | - |
