FQP6N40CF
MOSFET N-CH 400V 6A TO220-3Manufacturer: onsemi
Categories: Single FETs, MOSFETs
Quality Control: Learn More
The onsemi FRFET® series FQP6N40CF is a 400V N-Channel power MOSFET in a TO-220-3 package. This device offers a continuous drain current of 6A at 25°C (Tc) and a maximum power dissipation of 73W (Tc). Key electrical characteristics include a drain-to-source voltage (Vdss) of 400V, a low on-resistance (Rds On) of 1.1 Ohm maximum at 3A and 10V drive, and a gate charge (Qg) of 20 nC maximum at 10V. Input capacitance (Ciss) is specified at 625 pF maximum at 25V. The operating temperature range is -55°C to 150°C (TJ). This component is suitable for applications in power supply, lighting, and motor control.
Additional Information
Series: FRFET®RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-220-3 |
| Mounting Type | Through Hole |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Technology | MOSFET (Metal Oxide) |
| FET Type | N-Channel |
| Current - Continuous Drain (Id) @ 25°C | 6A (Tc) |
| Rds On (Max) @ Id, Vgs | 1.1Ohm @ 3A, 10V |
| FET Feature | - |
| Power Dissipation (Max) | 73W (Tc) |
| Vgs(th) (Max) @ Id | 4V @ 250µA |
| Supplier Device Package | TO-220-3 |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Vgs (Max) | ±30V |
| Drain to Source Voltage (Vdss) | 400 V |
| Gate Charge (Qg) (Max) @ Vgs | 20 nC @ 10 V |
| Input Capacitance (Ciss) (Max) @ Vds | 625 pF @ 25 V |
