FDZ293P
MOSFET P-CH 20V 4.6A 9BGAManufacturer: onsemi
Categories: Single FETs, MOSFETs
Quality Control: Learn More
onsemi FDZ293P is a P-Channel PowerTrench® MOSFET designed for high-efficiency power management applications. This device features a Drain-Source Voltage (Vdss) of 20V and a continuous drain current (Id) of 4.6A at 25°C ambient temperature. The on-resistance (Rds On) is specified at a maximum of 46mOhm at 4.6A and 4.5V gate-source voltage. The MOSFET offers a low gate charge (Qg) of 11 nC at 4.5V Vgs and an input capacitance (Ciss) of 754 pF at 10V Vds. Operating across a temperature range of -55°C to 150°C (TJ), the FDZ293P is supplied in a compact 9-BGA (1.5x1.6) package, suitable for surface mounting. This component finds application in portable electronics, consumer electronics, and automotive systems requiring robust power switching capabilities. The device supports drive voltages from 2.5V to 4.5V and has a maximum gate-source voltage of ±12V. The maximum power dissipation is 1.7W at ambient temperature.
Additional Information
Series: PowerTrench®RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 9-VFBGA |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Technology | MOSFET (Metal Oxide) |
| FET Type | P-Channel |
| Current - Continuous Drain (Id) @ 25°C | 4.6A (Ta) |
| Rds On (Max) @ Id, Vgs | 46mOhm @ 4.6A, 4.5V |
| FET Feature | - |
| Power Dissipation (Max) | 1.7W (Ta) |
| Vgs(th) (Max) @ Id | 1.5V @ 250µA |
| Supplier Device Package | 9-BGA (1.5x1.6) |
| Drive Voltage (Max Rds On, Min Rds On) | 2.5V, 4.5V |
| Vgs (Max) | ±12V |
| Drain to Source Voltage (Vdss) | 20 V |
| Gate Charge (Qg) (Max) @ Vgs | 11 nC @ 4.5 V |
| Input Capacitance (Ciss) (Max) @ Vds | 754 pF @ 10 V |
