EC4401C-TL
MOSFET N-CH 30V 150MA ECSP1008-4Manufacturer: onsemi
Categories: Single FETs, MOSFETs
Quality Control: Learn More
N-Channel 30 V 150mA (Ta) 150mW (Ta) Surface Mount 4-ECSP1008
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 4-UFDFN |
| Mounting Type | Surface Mount |
| Operating Temperature | 150°C (TJ) |
| Technology | MOSFET (Metal Oxide) |
| FET Type | N-Channel |
| Current - Continuous Drain (Id) @ 25°C | 150mA (Ta) |
| Rds On (Max) @ Id, Vgs | 3.7Ohm @ 80mA, 4V |
| FET Feature | - |
| Power Dissipation (Max) | 150mW (Ta) |
| Vgs(th) (Max) @ Id | - |
| Supplier Device Package | 4-ECSP1008 |
| Drive Voltage (Max Rds On, Min Rds On) | 1.5V, 4V |
| Vgs (Max) | ±10V |
| Drain to Source Voltage (Vdss) | 30 V |
| Gate Charge (Qg) (Max) @ Vgs | 1.58 nC @ 10 V |
| Input Capacitance (Ciss) (Max) @ Vds | 7 pF @ 10 V |
