2N7002WT1G
MOSFET N-CH 60V 310MA SC70-3Manufacturer: onsemi
Categories: Single FETs, MOSFETs
Quality Control: Learn More
N-Channel 60 V 310mA (Ta) 280mW (Tj) Surface Mount SC-70-3 (SOT323)
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 17 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SC-70, SOT-323 |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Technology | MOSFET (Metal Oxide) |
| FET Type | N-Channel |
| Current - Continuous Drain (Id) @ 25°C | 310mA (Ta) |
| Rds On (Max) @ Id, Vgs | 1.6Ohm @ 500mA, 10V |
| FET Feature | - |
| Power Dissipation (Max) | 280mW (Tj) |
| Vgs(th) (Max) @ Id | 2.5V @ 250µA |
| Supplier Device Package | SC-70-3 (SOT323) |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Vgs (Max) | ±20V |
| Drain to Source Voltage (Vdss) | 60 V |
| Gate Charge (Qg) (Max) @ Vgs | 0.7 nC @ 4.5 V |
| Input Capacitance (Ciss) (Max) @ Vds | 24.5 pF @ 20 V |
Request a Quote
