PCFF100H120SWF
1200V/100A GEN7 FRD HS SAWN-ON-FManufacturer: onsemi
Categories: Single Diodes
Quality Control: Learn More
onsemi's PCFF100H120SWF is a 1200V, 100A GEN7 Fast Diode (FRD) presented as a sawn-on-wafer surface mount component. This high-performance diode features a maximum forward voltage (Vf) of 2.08V at 100A and a remarkably low reverse leakage of 10 µA at its peak reverse voltage of 1200V. With a reverse recovery time (trr) of 347.1 ns, it is categorized as a fast recovery diode. The device operates across a junction temperature range of -40°C to 175°C. Its wafer form factor and robust specifications make it suitable for demanding applications in power conversion, industrial motor control, and renewable energy systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | Die |
| Mounting Type | Surface Mount |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 347.1 ns |
| Technology | Standard |
| Capacitance @ Vr, F | - |
| Current - Average Rectified (Io) | 100A |
| Supplier Device Package | Wafer |
| Operating Temperature - Junction | -40°C ~ 175°C |
| Grade | - |
| Voltage - DC Reverse (Vr) (Max) | 1200 V |
| Voltage - Forward (Vf) (Max) @ If | 2.08 V @ 100 A |
| Current - Reverse Leakage @ Vr | 10 µA @ 1200 V |
| Qualification | - |
