NSR05T40P2T5G
DIODE SCHOTTKY 40V 500MA SOD923Manufacturer: onsemi
Categories: Single Diodes
Quality Control: Learn More
onsemi NSR05T40P2T5G is a Schottky diode with a 40V reverse voltage rating and a 500mA average rectified current capability. This component is housed in a compact SOD-923 surface mount package. It features a low forward voltage of 700mV at 500mA and a reverse leakage current of 55µA at 40V. The diode exhibits a reverse recovery time of 8ns, classifying it as fast recovery. With a junction operating temperature range of -55°C to 150°C and a capacitance of 29pF at 4V and 1MHz, this device is suitable for applications in power management, consumer electronics, and automotive systems. The component is supplied in Tape & Reel packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SOD-923 |
| Mounting Type | Surface Mount |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 8 ns |
| Technology | Schottky |
| Capacitance @ Vr, F | 29pF @ 4V, 1MHz |
| Current - Average Rectified (Io) | 500mA |
| Supplier Device Package | SOD-923 |
| Operating Temperature - Junction | -55°C ~ 150°C |
| Voltage - DC Reverse (Vr) (Max) | 40 V |
| Voltage - Forward (Vf) (Max) @ If | 700 mV @ 500 mA |
| Current - Reverse Leakage @ Vr | 55 µA @ 40 V |
