NRVBS3200T3G
DIODE SCHOTTKY 200V 3A SMBManufacturer: onsemi
Categories: Single Diodes
Quality Control: Learn More
The onsemi NRVBS3200T3G is a Schottky barrier rectifier diode designed for demanding applications. This component features a 200V reverse voltage rating and a 3A average rectified forward current capability. Its low forward voltage drop of 840mV at 3A ensures efficient operation. The device exhibits a reverse leakage current of 1mA at 200V. Qualified to AEC-Q101 standards and designated with an Automotive grade, it is suitable for use in automotive systems. The NRVBS3200T3G is housed in a compact DO-214AA (SMB) package for surface mounting, delivered in Tape & Reel (TR) packaging. Its operating junction temperature range is from -65°C to 175°C.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | DO-214AA, SMB |
| Mounting Type | Surface Mount |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Technology | Schottky |
| Capacitance @ Vr, F | - |
| Current - Average Rectified (Io) | 3A |
| Supplier Device Package | SMB |
| Operating Temperature - Junction | -65°C ~ 175°C |
| Grade | Automotive |
| Voltage - DC Reverse (Vr) (Max) | 200 V |
| Voltage - Forward (Vf) (Max) @ If | 840 mV @ 3 A |
| Current - Reverse Leakage @ Vr | 1 mA @ 200 V |
| Qualification | AEC-Q101 |
