MBRS140T3H
DIODE SCHOTTKY 40V 1A SMBManufacturer: onsemi
Categories: Single Diodes
Quality Control: Learn More
onsemi MBRS140T3H is a Schottky barrier rectifier in a DO-214AA (SMB) surface-mount package. This diode features a maximum reverse voltage (Vr) of 40V and a continuous average rectified forward current (Io) of 1A. The forward voltage drop (Vf) is rated at 600mV at 1A. Reverse leakage current is specified as 1mA at 40V. The device operates over a junction temperature range of -65°C to 125°C. This component is suitable for applications requiring efficient rectification and low forward voltage, commonly found in power supply circuits, switching power supplies, and general-purpose rectification across various industrial and consumer electronics sectors.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | DO-214AA, SMB |
| Mounting Type | Surface Mount |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Technology | Schottky |
| Capacitance @ Vr, F | - |
| Current - Average Rectified (Io) | 1A |
| Supplier Device Package | SMB |
| Operating Temperature - Junction | -65°C ~ 125°C |
| Voltage - DC Reverse (Vr) (Max) | 40 V |
| Voltage - Forward (Vf) (Max) @ If | 600 mV @ 1 A |
| Current - Reverse Leakage @ Vr | 1 mA @ 40 V |
Request a Quote
