MBRM110LT3G
DIODE SCHOTTKY 10V 1A POWERMITEManufacturer: onsemi
Categories: Single Diodes
Quality Control: Learn More
onsemi MBRM110LT3G is a 10V, 1A Schottky barrier rectifier. This Surface Mount device, housed in a Powermite (DO-216AA) package, offers a low forward voltage of 365 mV at 1A. Its reverse leakage current is rated at 500 µA at 10V. Operating from -55°C to 125°C, this diode is suitable for applications requiring fast switching speeds. The MBRM110LT3G is commonly utilized in power supply and rectification circuits across various industries including consumer electronics and industrial automation. It is supplied in Tape & Reel packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | DO-216AA |
| Mounting Type | Surface Mount |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Technology | Schottky |
| Capacitance @ Vr, F | - |
| Current - Average Rectified (Io) | 1A |
| Supplier Device Package | Powermite |
| Operating Temperature - Junction | -55°C ~ 125°C |
| Voltage - DC Reverse (Vr) (Max) | 10 V |
| Voltage - Forward (Vf) (Max) @ If | 365 mV @ 1 A |
| Current - Reverse Leakage @ Vr | 500 µA @ 10 V |
