MBRM110LT3
DIODE SCHOTTKY 10V 1A POWERMITEManufacturer: onsemi
Categories: Single Diodes
Quality Control: Learn More
onsemi MBRM110LT3 is a 10V, 1A Schottky rectifier in a Powermite package. This surface mount diode offers a low forward voltage of 365 mV at 1A and a reverse leakage current of 500 µA at 10V. Its fast recovery time, categorized as =< 500ns, > 200mA (Io), makes it suitable for high-frequency switching applications. The device operates across a junction temperature range of -55°C to 125°C. The MBRM110LT3 is commonly utilized in power supply rectification, reverse polarity protection, and switching power applications within the telecommunications and industrial sectors. It is supplied on tape and reel.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | DO-216AA |
| Mounting Type | Surface Mount |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Technology | Schottky |
| Capacitance @ Vr, F | - |
| Current - Average Rectified (Io) | 1A |
| Supplier Device Package | Powermite |
| Operating Temperature - Junction | -55°C ~ 125°C |
| Voltage - DC Reverse (Vr) (Max) | 10 V |
| Voltage - Forward (Vf) (Max) @ If | 365 mV @ 1 A |
| Current - Reverse Leakage @ Vr | 500 µA @ 10 V |
