FFP08S60SNTU
DIODE GEN PURP 600V 8A TO220-2LManufacturer: onsemi
Categories: Single Diodes
Quality Control: Learn More
The onsemi STEALTH™ II series FFP08S60SNTU is a general-purpose diode designed for demanding applications. This fast-recovery diode features a 600 V reverse voltage (Vr) rating and an average rectified forward current (Io) of 8 A. Its low reverse leakage is specified at 100 µA at 600 V. The forward voltage drop (Vf) is a maximum of 3.4 V at 8 A. With a reverse recovery time (trr) of 32 ns, it is suitable for applications requiring efficient switching. The FFP08S60SNTU is housed in a TO-220-2L package, enabling through-hole mounting. Operating temperature ranges from -65°C to 150°C. This component finds utility in power supply, motor control, and industrial automation systems.
Additional Information
Series: STEALTH™ IIRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-220-2 |
| Mounting Type | Through Hole |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 32 ns |
| Technology | Standard |
| Capacitance @ Vr, F | - |
| Current - Average Rectified (Io) | 8A |
| Supplier Device Package | TO-220-2L |
| Operating Temperature - Junction | -65°C ~ 150°C |
| Voltage - DC Reverse (Vr) (Max) | 600 V |
| Voltage - Forward (Vf) (Max) @ If | 3.4 V @ 8 A |
| Current - Reverse Leakage @ Vr | 100 µA @ 600 V |
