2SC3902S
TRANS NPN 160V 1.5A TO126MLManufacturer: onsemi
Categories: Single Bipolar Transistors
Quality Control: Learn More
onsemi's 2SC3902S is an NPN bipolar junction transistor (BJT) in a TO-126ML package. This through-hole component offers a collector-emitter breakdown voltage of 160V and a continuous collector current capability of 1.5A. It features a transition frequency of 120MHz and a maximum power dissipation of 1.5W. The device exhibits a minimum DC current gain (hFE) of 100 at 100mA and 5V, with a Vce(sat) of 450mV at 50mA and 500mA. Collector cutoff current is specified at 1µA (ICBO). This component is suitable for applications in various industrial and consumer electronics markets.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | TO-225AA, TO-126-3 |
| Mounting Type | Through Hole |
| Transistor Type | NPN |
| Operating Temperature | 150°C (TJ) |
| Vce Saturation (Max) @ Ib, Ic | 450mV @ 50mA, 500mA |
| Current - Collector Cutoff (Max) | 1µA (ICBO) |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 100 @ 100mA, 5V |
| Frequency - Transition | 120MHz |
| Supplier Device Package | TO-126ML |
| Current - Collector (Ic) (Max) | 1.5 A |
| Voltage - Collector Emitter Breakdown (Max) | 160 V |
| Power - Max | 1.5 W |
