2SA1723
TRANS PNP 20V 0.3A TO126Manufacturer: onsemi
Categories: Single Bipolar Transistors
Quality Control: Learn More
onsemi PNP Bipolar Junction Transistor, part number 2SA1723. This device offers a 20V collector-emitter breakdown voltage and a maximum collector current of 300mA. Featuring a transition frequency of 1.5GHz and a power dissipation of 1.2W, it is supplied in a TO-126 package for through-hole mounting. The minimum DC current gain (hFE) is 15 at 50mA and 5V. This component is utilized in various applications, including consumer electronics and industrial control systems.
Additional Information
Series: -RoHS Status: Vendor undefinedManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | TO-225AA, TO-126-3 |
| Mounting Type | Through Hole |
| Transistor Type | PNP |
| Operating Temperature | - |
| Vce Saturation (Max) @ Ib, Ic | 1V @ 10mA, 100mA |
| Current - Collector Cutoff (Max) | 100nA (ICBO) |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 15 @ 50mA, 5V |
| Frequency - Transition | 1.5GHz |
| Supplier Device Package | TO-126 |
| Current - Collector (Ic) (Max) | 300 mA |
| Voltage - Collector Emitter Breakdown (Max) | 20 V |
| Power - Max | 1.2 W |
