NCV8402STCT1G
IC PWR MOSFET N-CH SOT223Manufacturer: onsemi
Categories: Power Distribution Switches, Load Drivers
Quality Control: Learn More
The onsemi NCV8402STCT1G is a power MOSFET designed for robust load switching applications. This N-Channel device features a low-side configuration and is packaged in a SOT-223 (TO-261) surface-mount format, supplied on tape and reel. The NCV8402STCT1G offers a continuous output current of up to 2A and is equipped with comprehensive fault protection, including fixed current limiting, over-temperature shutdown, over-voltage protection, and short-circuit protection. Its auto-restart feature enhances system reliability. With a typical Rds On of 165mOhm, this component is suitable for power distribution and load driver functions in automotive and industrial control systems. The operating temperature range is -40°C to 150°C (TJ).
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Features | Auto Restart |
| Packaging | Tape & Reel (TR) |
| Package / Case | TO-261-4, TO-261AA |
| Output Type | N-Channel |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Interface | ON/OFF |
| Switch Type | General Purpose |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Output Configuration | Low Side |
| Rds On (Typ) | 165mOhm |
| Input Type | Non-Inverting |
| Voltage - Load | 42V |
| Voltage - Supply (Vcc/Vdd) | Not Required |
| Current - Output (Max) | 2A |
| Ratio - Input:Output | 1:1 |
| Supplier Device Package | SOT-223 (TO-261) |
| Fault Protection | Current Limiting (Fixed), Over Temperature, Over Voltage, Short Circuit |
