FPF2702MX
IC PWR SWITCH N-CHANNEL 1:1 8SOManufacturer: onsemi
Categories: Power Distribution Switches, Load Drivers
Quality Control: Learn More
The onsemi AccuPower™ FPF2702MX is a high-side N-channel power switch designed for general-purpose applications. This 8-SOIC package device offers a 1:1 input-to-output ratio and supports a load voltage range of 2.8V to 36V with a maximum output current of 2A. Key features include adjustable current limiting, over-temperature protection, and undervoltage lockout (UVLO) for robust power management. The FPF2702MX also provides Power Good indication, slew rate control for managed turn-on, and a status flag. Its interface is a simple ON/OFF control. This component is commonly utilized in industrial automation, consumer electronics, and automotive systems where reliable power distribution is critical. The typical on-resistance (Rds On) is 88mOhm. The device is supplied in Tape & Reel packaging.
Additional Information
Series: AccuPower™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | Power Good, Slew Rate Controlled, Status Flag |
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Output Type | N-Channel |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Interface | ON/OFF |
| Switch Type | General Purpose |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Output Configuration | High Side |
| Rds On (Typ) | 88mOhm |
| Input Type | Inverting |
| Voltage - Load | 2.8V ~ 36V |
| Voltage - Supply (Vcc/Vdd) | Not Required |
| Current - Output (Max) | 2A |
| Ratio - Input:Output | 1:1 |
| Supplier Device Package | 8-SOIC |
| Fault Protection | Current Limiting (Adjustable), Over Temperature, UVLO |
