NCP1615C2DR2G
IC PFC CTL CCFF/CRM 26KHZ 16SOICManufacturer: onsemi
Categories: PFC (Power Factor Correction)
Quality Control: Learn More
The onsemi NCP1615C2DR2G is a Power Factor Correction (PFC) integrated circuit operating in Critical Conduction Mode (CRM) with Current Controlled Frequency Foldback (CCFF). This device is designed for high-efficiency power conversion applications, typically in the 26kHz switching frequency range. It features a wide supply voltage range from 9.5V to 28V and a low startup current of 12mA. The NCP1615C2DR2G is housed in a 16-SOIC package, suitable for surface mounting. Its capabilities make it a valuable component in power supplies for consumer electronics, industrial automation, and lighting systems. The operating temperature range is -40°C to 125°C. It is supplied in tape and reel packaging for automated assembly processes.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 16-SOIC (0.154"", 3.90mm Width), 15 Leads |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 125°C |
| Voltage - Supply | 9.5V ~ 28V |
| Frequency - Switching | 26kHz |
| Mode | Current Controlled Frequency Foldback (CCFF), Critical Conduction (CRM) |
| Supplier Device Package | 16-SOIC |
| Current - Startup | 12 mA |
