NIS6111QPT1
IC OR CTRLR N+1 32PLLPManufacturer: onsemi
Categories: OR Controllers, Ideal Diodes
Quality Control: Learn More
onsemi BERS™ Series NIS6111QPT1 is an N+1 ORing Controller featuring an integrated N-channel FET. This robust component is designed for high-reliability power systems, offering efficient power path management. With a maximum output current of 30A and a supply voltage range of 4.8V to 5.2V, it is suitable for demanding applications. The device boasts fast switching characteristics with a typical ON delay of 45 ns and an OFF delay of 35 ns. Its N:1 ratio configuration and internal switch functionality simplify complex power architectures. The NIS6111QPT1 is supplied in a 32-PLLP (9x9) package on tape and reel, suitable for surface mounting. Its operational temperature range of -40°C to 125°C ensures performance in challenging environments. This controller is commonly utilized in Flyback and Forward converter topologies within sectors such as industrial automation and telecommunications.
Additional Information
Series: BERS™RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 32-PowerQFN |
| Mounting Type | Surface Mount |
| Type | N+1 ORing Controller |
| Operating Temperature | -40°C ~ 125°C |
| Voltage - Supply | 4.8V ~ 5.2V |
| Applications | Flyback, Forward Converters |
| Internal Switch(s) | Yes |
| FET Type | N-Channel |
| Delay Time - ON | 45 ns |
| Delay Time - OFF | 35 ns |
| Current - Output (Max) | 30A |
| Ratio - Input:Output | N:1 |
| Supplier Device Package | 32-PLLP (9x9) |
| Grade | - |
| Current - Supply | 1.3 mA |
| Qualification | - |
