STK672-060-E
IC MOTOR DRIVER UNIPOLAR 22SIPManufacturer: onsemi
Categories: Motor Drivers, Controllers
Quality Control: Learn More
The onsemi STK672-060-E is a unipolar stepper motor driver featuring a fully integrated control and power stage. This 22-SIP package device leverages Power MOSFET technology for efficient operation. It supports multiple step resolutions including full, 1/2, 1/4, 1/8, and 1/16 steps, enabling precise motor control. The device operates with a load voltage range of 10V to 45V and a supply voltage of 4.75V to 5.25V, delivering an output current of 1.2A. Its output configuration utilizes two half bridges. The STK672-060-E is suitable for through-hole mounting and is rated for operation up to 150°C junction temperature. This component is widely applied in automation and industrial control systems.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 22-SIP |
| Mounting Type | Through Hole |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Current - Output | 1.2A |
| Interface | Parallel |
| Operating Temperature | 150°C (TJ) |
| Output Configuration | Half Bridge (2) |
| Voltage - Supply | 4.75V ~ 5.25V |
| Applications | General Purpose |
| Technology | Power MOSFET |
| Voltage - Load | 10V ~ 45V |
| Supplier Device Package | 22-SIP |
| Motor Type - Stepper | Unipolar |
| Motor Type - AC, DC | - |
| Step Resolution | 1, 1/2, 1/4, 1/8, 1/16 |
