LV8805V-TLM-H
IC MOTOR DRIVER 6V-15V 36SSOPJManufacturer: onsemi
Categories: Motor Drivers, Controllers
Quality Control: Learn More
onsemi's LV8805V-TLM-H is a Bi-CMOS parallel and PWM interface motor driver designed for brushless DC (BLDC) fan motor applications. This fully integrated component features control and power stages within a 36-SSOPJ package, suitable for surface mount installation. The device operates with a supply voltage ranging from 6V to 15V and supports a load voltage within the same range. It delivers an output current of 1.2A and offers a half-bridge output configuration with three such bridges. The operating temperature range for the LV8805V-TLM-H is -40°C to 95°C (TA). The 36-LSOP package, with an exposed pad, is provided on tape and reel for efficient manufacturing processes.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 36-LSOP (0.220"", 5.60mm Width) Exposed Pad |
| Mounting Type | Surface Mount |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Current - Output | 1.2A |
| Interface | Parallel, PWM |
| Operating Temperature | -40°C ~ 95°C (TA) |
| Output Configuration | Half Bridge (3) |
| Voltage - Supply | 6V ~ 15V |
| Applications | Fan Motor Driver |
| Technology | Bi-CMOS |
| Voltage - Load | 6V ~ 15V |
| Supplier Device Package | 36-SSOPJ |
| Motor Type - Stepper | - |
| Motor Type - AC, DC | Brushless DC (BLDC) |
| Step Resolution | - |
