LV8104V-TLM-H
IC MOTOR DRIVER 16V-28V 44SSOPManufacturer: onsemi
Categories: Motor Drivers, Controllers
Quality Control: Learn More
The onsemi LV8104V-TLM-H is a Bi-CMOS motor driver featuring a parallel interface, designed for efficient control of Brushless DC (BLDC) motors. This component, housed in a 44-SSOP package, operates within a supply voltage range of 16V to 28V. Its output configuration includes three pre-driver half-bridge stages, enabling robust motor control capabilities. The LV8104V-TLM-H is suitable for general-purpose applications across various industries, leveraging its surface-mount design for streamlined integration into electronic systems. The operating temperature range is specified as -20°C to 80°C.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 44-LSSOP (0.220"", 5.60mm Width) |
| Mounting Type | Surface Mount |
| Function | Controller - Speed |
| Current - Output | - |
| Interface | Parallel |
| Operating Temperature | -20°C ~ 80°C (TA) |
| Output Configuration | Pre-Driver - Half Bridge (3) |
| Voltage - Supply | 16V ~ 28V |
| Applications | General Purpose |
| Technology | Bi-CMOS |
| Voltage - Load | - |
| Supplier Device Package | 44-SSOP |
| Motor Type - Stepper | - |
| Motor Type - AC, DC | Brushless DC (BLDC) |
| Step Resolution | - |
