LB11970FV-W-AH
IC MOTOR DRIVER 4.5V-16V 18SSOPManufacturer: onsemi
Categories: Motor Drivers, Controllers
Quality Control: Learn More
The onsemi LB11970FV-W-AH is a fully integrated motor driver featuring a bipolar parallel interface with PWM control. This component is designed for driving Brushless DC (BLDC) motors and includes two half-bridge output configurations. It operates from a supply voltage of 4.5V to 16V and supports load voltages from 3.5V to 16V, with a continuous output current capability of 1.2A. The device is housed in an 18-SSOP package, suitable for surface mount applications. Operating temperature ranges from -30°C to 90°C. This motor driver is commonly utilized in fan motor driver applications across various industries requiring precise motor control.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 18-LSOP (0.173"", 4.40mm Width) |
| Mounting Type | Surface Mount |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Current - Output | 1.2A |
| Interface | Parallel, PWM |
| Operating Temperature | -30°C ~ 90°C (TA) |
| Output Configuration | Half Bridge (2) |
| Voltage - Supply | 4.5V ~ 16V |
| Applications | Fan Motor Driver |
| Technology | Bipolar |
| Voltage - Load | 3.5V ~ 16V |
| Supplier Device Package | 18-SSOP |
| Motor Type - Stepper | - |
| Motor Type - AC, DC | Brushless DC (BLDC) |
| Step Resolution | - |
