LB11964FA-BH
IC MOTOR DRIVER 3.5V-18V 8MICROManufacturer: onsemi
Categories: Motor Drivers, Controllers
Quality Control: Learn More
The onsemi LB11964FA-BH is a bipolar motor driver with an integrated control and power stage. This fully integrated component is designed for brushed DC motor applications, featuring an ON/OFF interface for straightforward control. It provides a half-bridge output configuration, capable of driving motors with a load voltage ranging from 3.5V to 18V, with a supply voltage requirement also within the 3.5V to 18V range. The device delivers an output current of up to 500mA. Packaged in an 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) with surface mount mounting, it operates within an ambient temperature range of -30°C to 85°C. This component is commonly utilized in fan motor driver applications.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-TSSOP, 8-MSOP (0.118"", 3.00mm Width) |
| Mounting Type | Surface Mount |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Current - Output | 500mA |
| Interface | ON/OFF |
| Operating Temperature | -30°C ~ 85°C (TA) |
| Output Configuration | Half Bridge (2) |
| Voltage - Supply | 3.5V ~ 18V |
| Applications | Fan Motor Driver |
| Technology | Bipolar |
| Voltage - Load | 3.5V ~ 18V |
| Supplier Device Package | 8-Micro |
| Motor Type - Stepper | - |
| Motor Type - AC, DC | Brushed DC |
| Step Resolution | - |
