FNB80560T3-01
FNB80560T3-01Manufacturer: onsemi
Categories: Motor Drivers, Controllers
Quality Control: Learn More
The onsemi Motion-SPM® series FNB80560T3-01 is a fully integrated multiphase motor driver. This component combines control logic and a power stage utilizing IGBT technology for Brushless DC (BLDC) and multiphase stepper motor applications. The output configuration features six half-bridge drivers, enabling efficient motor control. Designed for robust operation, it supports an operating temperature range of -40°C to 150°C (TJ). The FNB80560T3-01 is housed in a 25-PowerDIP Module (0.815", 20.70mm) with a through-hole mounting type. Its interface is logic-level, and it provides an output current of 5A. This device is suitable for general-purpose applications across various industries requiring precise motor control.
Additional Information
Series: Motion-SPM®RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 25-PowerDIP Module (0.815"", 20.70mm) |
| Mounting Type | Through Hole |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Current - Output | 5A |
| Interface | Logic |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Output Configuration | Half Bridge (6) |
| Voltage - Supply | - |
| Applications | General Purpose |
| Technology | IGBT |
| Voltage - Load | - |
| Supplier Device Package | SPMFA-A25 |
| Motor Type - Stepper | Multiphase |
| Motor Type - AC, DC | Brushless DC (BLDC) |
| Step Resolution | - |
